Microphone Handling and Storage

XVI.

SPECIFICATIONS

38

XVII.

ADDENDUM FOR THE MODEL 2800-5

The microphones used with the model 1900 will provide years of reliable use, but certain precautions should be followed with regard to handling and storage.

... ...

40

SERVICE AND WARRANTY POLICY... Service Policy... Warranty Policy...

41 41 41

With the microphone and preamplifier removed, the meter can accept other input devices such as the Quest Model VI-90 Vibration Integrator. The VA-508C Vibration Assembly, combined with the Model 2800, provides a quick and precise method of measuring and analyzing many types of industrial vibration. A. Assembling the Meter The microphone and preamplifier must be assembled prior to making any measurements.

1.

Never remove the microphone grid. This will expose the diaphragm, making it susceptible to physical damage. When removing a microphone from the preamplifier be careful not to unscrew only the grid. Figure 1 Preamp Assembly 1

2.

Never touch the diaphragm.

3.

Electret (prepolarized) microphones should never be stored at high temperatures, as long term degradation of the polarization charge may occur. This results in a decrease in microphone sensitivity.

4.

An electret microphone should be stored in its protective box when not in use for long periods of time.

To attach the microphone to the preamplifier, screw the microphone onto the threaded end of the preamplifier. Attach the preamplifier to the meter by placing the connector ends together and rotating the preamplifier until it drops onto the meter. Finger tighten the black locking ring by screwing it onto the meter. II.

ABOUT THE METER

A. The Display The LCD display contains both a numeric readout and a bar indicator along with BAT (battery), RUN, HLD (hold), and OL (overload) annunciators. The rate at which the numeric display is updated depends upon the setting of a switch located in the battery compartment. Either a one-second or a one-quarter second display rate can be selected. The bar indicator portion of the display will indicate the current SPL (Sound Pressure Level), except when the BATTERY button is pressed. (See III. A., Battery Check). When using the bar indicator for SPL, the 0 to 60 range of the bar indicator represents the selected range on the Range switch. If on the 80 to 140 range, for example, the bar indicator represents 80 to 140 dB. The MODE switch selects what data is to be displayed in the digital portion of the readout (i.e. SPL, MIN, MAX etc.). Sound levels are shown to the nearest 0.1 dB. RUN time (or OL time) is displayed in MIN:SEC if the total time is less than 20 minutes, and in HRS:MIN if the total time is greater than 20 minutes.

2

3

RESPONSE Switch

B. Meter Controls HOLD Button When the HOLD button is depressed, the current value in the numerical portion of the display is frozen and the HLD annunciator appears in the display. If the meter is in the RUN mode while or prior to pressing the HOLD button, the last stored values of MIN, MAX, SEL, TIME, and LEQ that occurred can be viewed. Simply use the MODE switch to select the value of interest. Pressing HOLD will NOT stop an LEQ measurement accumulation. It simply saves the current value for viewing.

SLOW -

1 second time constant. (See Figure 14)

FAST -

125 millisecond time constant. (See Figure 15)

PEAK -

RESET Button

50 microsecond rise time constant with the peak sound level being captured and held until the RESET button is pressed. (See Figure 16)

To reset ALL data stored within the Model 2800, press the RESET button. This will erase all stored data prior to taking new readings.

NOTE: Pressing the RESET button while in the response will not clear out the integration data.

HOLD is a toggle function. again.

NOTE:

To exit the HOLD mode simply press HOLD

Pressing RESET while the RESPONSE is set to PEAK only resets PEAK. All other data remains unaffected.

PEAK

IMPulse - 35 millisecond rise time constant with a decay rate of 2.9 dB/sec. (See Figures 17 and 18)

RUN Button

WEIGHTING Switch

The RUN indicator will appear in the display when the RUN button is pressed. The meter will begin integration at this point. MAX, MIN, SEL, TIME, and LEQ data is collected only during the RUN mode. Pressing the RUN button again will exit the RUN mode and the instrument will enter the PAUSE mode where MAX, MIN, SEL, TIME, and LEQ are held at their last values. Press the RUN button again to continue updating MAX, MIN, SEL, TIME, and LEQ. Press RESET to erase all existing data before taking new data.

The WEIGHTING switch controls the frequency response of the meter. Weightings A, B, C, or LINear (flat) may be selected. (See V. E., Weighting Characteristics for further details.)

PRINT Button

MODE Switch The MODE switch selects either the sound pressure level or the integrating function to be shown in the digital portion of the display. (MIN, MAX, SEL, TIME, and LEQ will only have values if the meter has been in the RUN mode accumulating data.)

If the Model 2800 is connected to a printer via the PRINT output jack, pressing the PRINT button will send all of the current data stored in the meter to the printer. During the printout period, the numeric display will read 'Prn'. To stop the printout just press the print button again. (See Figure 5, sample Printout.)

SPL -

Sound Pressure Level will be displayed. (SPL is also always shown in the display bar indicator.)

MAX -

The Maximum Sound Pressure Level obtained in the RUN mode is shown in the numeric display.

BATTERY Button

MIN -

The Minimum Sound Pressure Level obtained while in the RUN mode is shown in the numeric display.

SEL -

The Sound Exposure Level, or sound energy averaged over one second that is equivalent to the energy accumulated while in the RUN mode, is displayed.

Pressing the BATTERY button will indicate relative battery strength in the bar portion of the display. This button may be pressed at any time without affecting the meter signal processing. (See III. A., Battery Check for more information.)

4

The RESPONSE switch controls the rate at which the meter responds to changing input signals. Most sound measurements are done with the response set to SLOW. The FAST response is generally used when measuring short duration noises such as moving vehicles. PEAK is only used in the SPL mode and has no meaning when making integrated measurements. The RESPONSE switch positions are as follows:

5

TIME -

The total RUN time will be displayed. The format is MIN:SEC for any time less than 20 minutes and HRS:MIN for any time greater than 20 minutes.

D. Output Jacks

LEQ -

The average integrated sound level accumulated while in the RUN mode is displayed.

All output jacks use a 3.5 mm stereo plug. (See Figure 2, Output Jack Connections.) The following describes each output function:

dB RANGE Switch The displayed range of the Model 2800 is 60 dB and is switchable between the following: 20-80 dB, 40-100 dB, 60-120 dB, or 80-140 dB. POWER Switch When turned ON, the meter begins with all data reset to zero and is in the pause mode (non-RUN mode). By switching the unit OFF, all accumulated data is cleared from the memory.

Figure 2. Output Jack Connections

C. Overload Detection In the SPL mode, the overload indicator (OL) is displayed whenever the incoming signal saturates (overloads) the circuitry. It appears as OL in the upper right-hand corner of the display. If the OL indicator is on, increase the dB RANGE switch until the OL condition is removed causing OL to disappear. The Model 2800 also stores the length of time that the OL condition existed during the RUN mode. If an OL condition occurs while in the RUN mode, the OL indicator will come on and remain on until RESET is pressed. The time duration of the overload condition can be viewed by sliding the MODE switch to TIME and then holding the BATTERY button in. The overload time will also be printed on the hard copy printout. Note: OL can be reset for use in the SPL mode without losing accumulated data. Place the meter into PAUSE, slide the RESPONSE switch to PEAK and then press the RESET button. Then return the RESPONSE switch back to the desired position. OL is now reset for normal use in the SPL mode only. It still remains latched when switched back to either the SEL, TIME, or LEQ mode.

6

PRINT -

Pressing the PRINT button causes serial ASCII data to be transmitted from the print jack at appropriate RS-232 levels. This data may be sent to a serial printer or a computer. The baud rate is determined by two switches located in the battery compartment. (See Figure 4, Battery Compartment Internal Switches, for switch settings).

DC -

The Sound Pressure Level (SPL) over the 60 dB range selected is linearly represented by a 0 to 1 volt DC output. Zero volts is equal to the bottom of the range and 1 volt is equal to full scale. This output is primarily provided for connecting to a 0 to 1 volt input chart recorder. (See IV. D., Chart Recording and Figure 6, Chart Recording of SPL)

AC -

This jack furnishes an amplified SPL, (either weighted or unweighted), depending on the WEIGHTING switch setting. The full span of 60 dB is represented between 3.16 millivolts and 3.16 volts RMS.

DATA -

When the Model 2800 is in the RUN mode, an SPL reading will be serially transmitted through the DATA jack at a rate of 16 times per second. To make use of this function, the meter range switch must be set in one of its two highest positions.

7

The data is an 8-bit signal proportional to the integrated sound level for the last 1/16 second. The signal is normally at +6.5 volts. If the meter is in the RUN mode, data is sent as in Figure 3. Signal description is as follows: The signal goes to -6.5 volts every 0.55 msec. If the bit is a 0 it will return to plus after 0.1 msec. If the bit is a 1 it will return plus after 0.45 msec. The signal is sent least significant bit first. The resolution is 3/8 dB. All 0's = 30 dB if the meter is set to the 60 - 120 dB range. 50 dB if the meter is set to the 80 - 140 dB range. All 1's = 30 dB + 95.6 dB when set to the 60 - 120 dB range. 50 dB + 95.6 dB when set to the 80 - 140 dB range. The example in Figure 3 is 10101100 binary = 172 decimal. x 3/8) + 50 = 114.5 dB when on the 80 - 140 dB range.

The level is (172

E . Internal Switches There is a n internal s w i t c h located in t h e Figure 3. Data Jack Format battery compartmen t that is accessible to the user. (Refer to Figure 4.) Baud Rate -

Actuators 1 and 2 of the dip switch, located through the hole in the lower left, control the baud rate at which the meter transmits data to a printer. Baud rates available are 300, 600, 1200, and 2400.

Display Time - The recessed dip switch controls the rate at which the display updates. The options are 1.0 second or 0.25 second.

8

F . Printout The Sound L e v e l M e t e r produces a hard-copy of the informatio n accumulate d during the total RUN MODE period. When used with the filter set Figure 4. Battery Compartment Internal Switches. OFF, this informatio n includes : 1. 2. 3. 4.

Meter WEIGHTING and RESPONSE settings. LEQ, MAX, MIN, and SEL Levels. RUN TIME and OL TIME. Table of EXCEEDANCE LEVELS (dB)*

*EXCEEDANCE LEVELS: Tabulated from 1 to 99, the sound level that was exceeded for that percentage of run time. (See Figure 5, Sample Printout.) If an OB-100 or OB-300 is actively used as part of the sound measuring system, all of the information above the OCTAVE FILTER SET header will pertain only to the last Octave Band measurement. This allows the user to perform, for example, a 500 Hz Octave Band Measurement on "A" Weighting, "SLOW" Response, and obtain a printout that includes proper switch settings and exceedance levels for that frequency. NOTE:

For forty column printers, the Sound Level Meter allows for a compressed print mode. Pressing the HOLD button before printing causes the meter to send a printer control code [ LPRINT CHR$ (15) ] that produces a compressed print form for many printers. Consult your printer manual for details.

9

III.

CHECKING THE METER INTEGRITY

A. Battery Check QUEST MODEL 2800 IMPULSE INTEGRATING SOUND LEVEL METER DATE:_______ SERIAL NO. _______ CALIBRATED: __________ LINEAR WEIGHTING / SLOW RESPONSE LEQ(dB) MAX(dB) MIN(dB) SEL(dB) 100.8 107.2 49.4 116.3

RUN-TIME :00:36

EXCEEDANCE LEVELS(dB) 0 1 2 3 L00 107 107 107 107 L10 107 107 107 107 L20 107 106 106 106 L30 98 97 95 94 L40 89 89 88 88 L50 88 88 88 88 L60 87 87 87 87 L70 80 78 77 75 L80 65 64 63 62 L90 55 54 53 53

7 107 107 103 90 88 88 84 70 57 51

4 107 107 106 93 88 88 87 74 61 52

5 107 107 105 92 88 88 87 73 59 52

6 107 107 104 91 88 88 86 71 58 51

8 107 107 101 89 88 87 83 68 56 50

OL-TIME

9 107 107 100 89 88 87 81 67 56 50

B. Calibration To check the calibration of the Model 2800, perform the following procedure using a Quest Calibrator.

MODEL OB-300 1/1-1/3 OCTAVE FILTER SET - SERIAL NO. ______ FREQ(Hz) LEQ(dB) MAX(dB) MIN(dB) SEL(dB) 12.5 70.1 70.8 70.1 77.8 16 88.0 88.8 86.9 92.3 20 106.2 107.2 104.6 111.3 25 105.1 108.3 93.7 117.1 31.5 92.3 97.4 84.7 97.3 40 76.6 80.9 70.4 81.0 50 66.2 75.7 53.6 76.8 63 53.3 56.2 51.7 59.2 80 65.9 71.6 60.3 72.1 100 70.0 70.8 68.9 75.8 125 88.2 89.2 86.9 92.7 160 115.3 120.3 104.6 127.5 200 111.2 116.2 106.4 116.5 250 95.2 103.1 86.2 103.5 315 74.6 83.2 61.4 85.9 400 70.9 71.9 69.7 76.0 500 88.8 89.9 87.7 92.7 630 107.2 108.3 105.7 113.1 800 98.2 103.8 91.8 104.3 1,000 77.9 88.4 71.2 89.2 1,250 87.8 88.8 86.6 92.3 1,600 113.0 120.3 64.1 126.6 2,000 109.8 116.2 100.8 118.2 2,500 91.3 96.7 82.8 96.9 3,150 72.9 79.4 66.3 81.3 4,000 90.1 91.1 89.2 92.1 5,000 106.0 106.8 104.6 110.3 6,300 99.6 102.7 95.9 102.1 8,000 80.8 84.3 77.2 83.6 10,000 67.5 74.2 61.4 75.0 12,500 71.2 71.9 70.8 75.5 16,000 90.3 91.1 88.8 94.6 20,000 100.8 107.2 49.4 116.3

RUN-TIME :00:05 :00:02 :00:03 :00:15 :00:03 :00:02 :00:11 :00:03 :00:04 :00:03 :00:02 :00:16 :00:03 :00:06 :00:13 :00:03 :00:02 :00:03 :00:04 :00:13 :00:02 :00:23 :00:07 :00:03 :00:06 :00:01 :00:02 :00:01 :00:01 :00:05 :00:02 :00:02 :00:36

At any time (except during PRINT), the BATTERY push button can be pressed to get an indication of battery strength. The weaker of the two 9 volt batteries is shown on the bar indicator of the Model 2800's display. Good batteries will be indicated with the bar extending well beyond the indicating arrow (5 on the 0-60 scale). If the bar falls below the indicating arrow, then BOTH ALKALINE batteries must be replaced. Because erroneous readings will occur if the battery check registers below the indicating arrow, it is good practice to perform a battery check before using the 2800. Collected data and output port signals are NOT affected by performing a battery check.

OL-TIME

:00:05

1.

Perform a battery check.

2.

Turn the Calibrator ON to produce the level specified on the label at 1 kHz.

3.

An adapter is needed to mate the microphone size to the calibrator coupler. Insert it fully into the calibrator.

4.

Place the Calibrator with adapter fully onto the microphone.

5.

Set the Model 2800 to LIN, SLOW or FAST, the SPL mode, and the 60120 range.

6.

Use a small screwdriver to adjust the calibration potentiometer, located through the small hole on the left side of the meter, until the display matches the calibration level.

:00:04 :00:06

NOTE:

Most Calibrators (including Quest Calibrators) are affected by changes in altitude and barometric pressure. The rated SPL is set at standard barometric pressure at sea level (760 mm Hg). Consult the Calibrator Manual for correction factors at different altitudes and how to apply them.

Figure 5. Sample Printout 10

11

IV.

GENERAL OPERATING CONSIDERATIONS

Before taking measurements with the Model 2800, there is a series of quick checks and considerations that should be performed or noted. After switching the unit ON, the batteries should be checked (and replaced if needed). Although the Model 2800 will maintain accurate calibration over a long period of time, the calibration should be checked and the meter slightly adjusted, if necessary, before each use. Set the RESPONSE, WEIGHTING, MODE, and dB RANGE switches as needed. Hold, set, or tripod mount the meter in the desired location. If performing integrating measurements, press the RUN button making sure "RUN" is indicated in the display. If the meter is in the RUN mode and you want to change a switch setting (particularly the dB RANGE switch), it is a good idea to stop accumulating data by entering the pause mode. To do this depress the RUN button again and "RUN" will disappear from the display. Change the desired switches, and then depress RUN again to continue accumulating data. It is always a good idea to document all measurement conditions and meter settings for possible future needs. If a printer is used, the settings will all appear on the printout. A. Meter / Microphone Placement Whenever possible, the meter should be tripod-mounted in a relatively open area to minimize reflections from the body or other large reflective structures. Avoid placement against a wall or in a corner. If reflections are of concern, a microphone extension cable may be used for better microphone placement.

C. Wind S c r e e n Effects To prevent erroneous measuremen t of sound l e v e l s caused by w i n d blowing across the microphone , the use o f a windscreen i s recommende d. The w i n d s c r e e n w i l l r e d u c e Figure 6 Effect of Background on Measurement w i n d effects and will also help protect the microphone under dusty, oily, or humid conditions. Acoustic attenuation effects of the (WS-7) windscreen is shown in Figure 7.

The QE7052 microphone cartridge used on the Model 2800 is a free-field microphone. Point it directly at the noise source ( 0 degrees ). B. Background Noise Background noise can cause considerable error in measurement when its intensity is close to that of a particular noise source of interest. When it is not possible to eliminate or reduce the background noise, use the curve shown in Figure 6 to correct for the effect of the background noise on the measurement.

Figure 7. Acoustic Effect of WS-7 Windscreen

12

13

D. Chart Recording The Model 2800 has a DC output that is linearly related to the 60 dB LCD analog bar movement as follows: Analog Bar (dB) 0 DC Output (V) .00

10 .17

20 .33

30 .50

40 .67

50 .83

60 1.00

This output, capable of driving up to 100 feet of shielded or twisted pair cable, is intended for use with a 0 to 1 volt DC input chart recorder that has an input impedance greater than 20K ohms. Refer to Figure 8, Chart Recording of SPL. Connect the Model 2800 to the chart recorder input with proper polarity such that the pen is on the proper side of the chart paper with respect to time and that the pen moves in the proper direction with increasing dB level. Use a 1 kHz acoustic calibrator to calibrate the chart recorder as follows: 1. NOTE: 2.

3.

4.

Turn the meter to ON. Set the meter RESPONSE to FAST, WEIGHTING to A, MODE to SPL, and dB RANGE to 80-140. An adapter is needed to mate the microphone size to the calibrator coupler. Insert it fully into the calibrator. Place the calibrator with adapter fully onto the microphone - do not turn the calibrator on yet. The meter shall read less than 80 dB which generates .00 volts DC out to the chart recorder. Adjust the zero control on the recorder so that the pen represents a relative dB of 0. Turn the Calibrator ON to produce the level specified on the label at 1 kHz. Set the 2800 dB RANGE for the highest bar graph level without causing and overload. The recorder pen should rise to the correct RELATIVE dB. A small adjustment may be needed. Use the zero adjust to do this. Be sure to document all chart recorder settings and meter settings when taking measurements.

E. Data Logging with the NL-15 The Quest M o d e l N L - 1 5 Noise Data Logger can be used with the Q u e s t M o d e l 2 8 0 0 . When used with the meter, the following conditions Figure 8. Chart Recording of SPL must be observed: 1.

Set the RESPONSE switch on the meter to FAST. (The NL-15 will convert FAST to SLOW as required.)

2.

Set the dB RANGE switch to either 80 - 140 dB or 60 - 120 dB. (If used on other ranges, all data will be in error by either 20 dB or 40 dB.)

3.

Set the WEIGHTING switch on the meter to either A or C. If other weightings are used, the weighting data on the printout will be in error. The rest of the readings will be correct.

In addition, the internal switches in the NL-15 must be set to agree with the sound level meter settings. 1.

If the meter is to be used on the 80 - 140 dB range, set NL-15 internal switch 1, position 4 to OFF. If the meter is to be used on the 60 - 120 dB range, set NL-15 internal switch 1, position 4 to ON.

2.

If the meter is set to A-weighting, set NL-15 internal Switch 1, position 3, to OFF.

Note that any range position can be set on the Model 2800 and the 60 dB span of the meter range will always correspond to the full 60 dB range on the chart recorder. Use QUEST CHART PAPER # 58-653.

If the meter is set to C-weighting, set NL-15 internal switch 1, position 3, to ON.

14

15

The remainder of the internal switch settings are set the same as they would be for a Micro-15. Consult the NL-15 manual for complete instructions. The NL-15 will accumulate data when it is connected to the meter DATA OUTPUT jack if the following two conditions are met: 1.

The LED on the NL-15 is blinking.

2.

The RUN annunciator on the meter display is on.

To operate: 1.

Connect the two units. Note: An adapter cable from Quest is needed to adapt the NL-15 micro plug to the 3.5 mm DATA jack on the meter. (Quest Part Number 59-748, 1800/2800 to NL-15 Cable)

2.

Turn ON the NL-15 and RESET it.

3.

Press the RUN button on the meter.

4.

After sufficient data is accumulated, press the RUN button on the meter to enter the Pause mode.

5.

Connect the NL-15 to a printer and print the data. The setting of the remainder of the switches and push buttons will not affect the data stored in the NL-15. MODE, HOLD, PRINT, and BATTERY will not change the data stored. If RUN (on the meter) is toggled off, the NL-15 will accumulate null data. If toggled back on, it will accumulate additional data.

If an octave filter is connected to the meter when used with the NL-15, the NL-15 will accumulate the filtered data. To obtain data on multiple filter bands, print out the data after each filter frequency and then reset the NL-15. (The weighting in the summary will, of course, be wrong since the filter is now in series with either A, B, C, or LIN.) V.

Figure 9. Block Diagram of the Model 2800

TECHNICAL INFORMATION

A. Principles of Operation The Quest Model 2800 utilizes low noise, low power analog and digital integrated circuitry to ensure long battery life, maximum stability, and superior reliability over a wide range of environmental conditions. Figure 9 is a block diagram of the Model 2800's internal circuit operations.

16

17

B. Microphone

D. Input Buffer Circuitry

The Model 2800 is designed to accept a prepolarized (electret) microphone Model QE7052 exclusively.

The high impedance input circuitry (1 Megohm in series with 0.1 MFD) will accept up to a 10 volt RMS signal. With the microphone and preamp removed, other transducer devices (such as the Quest Model VI-90 Vibration Integrator) can be interfaced to give a dB readout on the meter.

The microphone screws directly onto the preamp which, in turn, connects directly to the meter. The preamp converts the high output impedance of the microphone into a low output impedance. This allows the microphone to drive up to 100 feet of cable for remote operation. A typical response curve for the .5 inch microphone is shown in Figure 10. C . Microphone P r e a m p Extension Cables

ICM-10 ICM-50

10 Ft. Remote Cable. 50 Ft. Remote Cable.

The preamp is removable by turning the black plastic collar below the preamp housing counter-clockwise when viewed from the top of the meter.

18

To remove the preamp, keep the preamp housing steady while unscrewing the black plastic collar below the preamp housing. Turn in a counter-clockwise direction when viewed from the meter top. To input an AC voltage electrically requires a special connector - Quest part number 14-739. Figure 11 describes the function of each of the pins within the meter input connector.

T h e microphone p r e a m p converts the high o u t p u t impedance of the microphone to a low o u t p u t impedance, Figure 10. Typical Frequency Response for the Model QE7052 .5 Inch Microphone t h u s allowing the insertion of an extension cable of up to 100 feet in length between the preamp and meter. Quest Electronics offers the following lengths of remote cables: # 59-733 # 59-734

When interfacing other input devices to the Model 2800, Use pins 1 and 3 for the AC signal input. NEVER connect to pins 2 and 4.

E . Weighting Characteri stics T h e weighting characteri s t i c s (frequency response) for A, B, C, and LINear are shown in Figure 12. Figure 11 Meter Electrical Input (Direct) The "A" weighting response emulates the response of the human ear and is used for most industrial and community noise measurements. "B" weighting is seldom used. "C" weighting is often used for measuring noise reduction in hearing protectors and for other scientific purposes. The "LINear" weighting has a flat frequency response over the range of human hearing and is useful in many applications such as audiometric analysis. It is also used when taking octave and 1/3 octave measurements.

19

G. Response Charts Figures 14 through 18 are plots for each of the response settings of the meter. They show how the meter responds to a given sinewave input of varied pulse duration.

F . Internal Electrical Noise

SLOW RESPONSE (1000 msec time constant)

T h e maximum measurable SPL of the 2800 Meter is 140 dB. When used w i t h either the OB-100 or O B - 3 0 0 f i l t e r set, the Figure 12 Weighting Characteristics specific minimum measurable SPL's in each octave band are as shown in Figure 13. The inherent noise level is typically at least 5 dB below the RMS values shown in the table.

Octave Band All Pass 31.5 and 63 125 and 250 500 and 1K 2K and 4K 8K and 16K

FAST RESPONSE (125 msec time constant)

Figure 14. Figure 15.

PEAK RESPONSE (50 microsecond time constant)

Figure 16.

IMPULSE RESPONSE (35 msec rise time constant with a decay 2.9 dB/sec) Figure 17 and Figure 18.

rate of

Weighting Scale A

B

C

LIN

35 10 21 24 27 29

37 25 27 25 25 27

40 35 31 25 25 27

48 37 31 25 25 30

Figure 14. SLOW Response

Figure 13. Minimum measurable SPL's for the Model 2800 with the QE7052 Microphone

20

21

Figure 16 PEAK Response

Figure 15

FAST Response

Figure 18

Figure 17

22

IMPULSE Response to Repeated Impulses

IMPULSE Response

23

VI.

SPECIFICATIONS

Standards: Meets or exceeds ANSI S1.4-1983, Type 2 and relevant sections of IEC 651-1979, Type 2(I) and IEC 804-1985. Display: 3 1/2 Digit Liquid Crystal Display with an additional Quasi-Analogue 60 dB indicator in 2 dB increments. Level display indicates to 0.1 dB resolution. Time display indicates either Min:Sec or Hr:Min. Annunciators are included for Battery Check, Hold, and Overload Indication. Printout: When used with a printer, a one page printout is produced. It consists of the following: Heading; WEIGHTING and RESPONSE settings; LEQ, MAX, MIN, and SEL levels; RUN TIME and OL TIME ; EXCEEDANCE LEVELS (dB) with 1 dB resolution; and Filter Data for each frequency (LEQ, MAX, MIN, and SEL) along with the RUN TIME and OL TIME for each frequency.

DC Output: 0 to 1.00V DC; 60 dB span. Each 0.167V change equals 10 dB. Connected equipment should be at least 10K ohms. The output can be shorted without damaging the meter or changing the meter reading. Print Output: Serial output to printers or computers using RS-232 voltage levels. Selectable baud rates of 300, 600, 1200, or 2400. ASCII character format. Data Output: Output transmission of real-time digital data occurs at a rate of 16 times per second using RS-232 voltage levels. Frequency Range: 4 Hz (-3dB) to 50 kHz (-3dB) on linear weighting, meter only. (Subject to microphone limitations.) Reference Range:

60 to 120 dB Range setting

Modes of Operation: Sound Pressure Level (SPL), Maximum Level (MAX), Minimum Level (MIN), Sound Exposure Level (SEL), and Equivalent Level (LEQ). Peak Level (PEAK) and Impulse Level (IMP) can also be measured.

Reference SPL:

Minimum Measurement: Meter only; With Model QE7052 Microphone -- 35 dBA. Using Linear Weighting with an Octave Filter Set; See Figure 13. The minimum measurement varies depending on the filter frequency selected.

Reference Direction: 0 Degree when using the Model QE7052 Microphone (Free Field). Sound is arriving from directly in front of the microphone diaphragm. (A Normal Line extending from the center of the microphone diaphragm.)

Maximum Measurement: With Model QE7052 Microphone -- 120 dB with 20 dB Crest Factor. (140 dB if measuring a sinusoidal signal.) Overload indication will occur if upper range is exceeded.

94 dB

Reference Frequency:

Detector:

True RMS

Detector Pulse Range: Frequency Weighting Networks: A, B, C, and Linear. any one of the weightings may be selected.

1 kHz

63 dB

When using a filter set,

Meter Response: Slow, Fast, Impulse, and Peak. (The Peak onset time constant is less than 50 microseconds). Peak measurements may be made in either A, B, C, or Linear Weighting.

Detector Measuring Range: From 0 dB to 40 dB on the painted scale (when measuring a signal with a 20 dB Crest Factor). The extra 20 dB (40 to 60) on top of the measuring range produces the 20 dB Crest Factor capability .

condenser

Primary Indicator Range / Linearity Range: 60 dB (The range as indicated by both the dB RANGE switch and the painted 60 dB scale.) Tested with a sinusoidal signal input.

Preamp: Removable; The input impedance is greater than 1G ohm in parallel with 35 pF. The preamp will drive up to 100 feet of cable.

Level Linearity: Inside the Primary Indicator Range. It is tested on the Reference Range (60 to 120 dB) with a sinusoidal input signal. Tolerance is +/- 1.0 dB referenced to 94 dB.

Meter Input: The input impedance is 1 Megohm in series with 0.1 MFD. maximum sinusoidal input voltage is 10V RMS.

Overload Indication: LCD.

Microphone: Model QE7052, (electret) microphone.

Removable

.5-inch

prepolarized

The

AC Output: 3.16 V RMS at full scale (60 dB). (3.8 V RMS maximum) The output impedance is 3.2K ohms. Connected equipment should be at least 10K ohms. The output can be shorted without damaging the meter or changing the meter reading.

Attenuator Accuracy: Referenced from the Reference Range and the Reference SPL (+34 dB on the painted meter scale). Within 0.7 dB from 31.5 Hz to 8 kHz. Warm-up Time:

24

The display annunciator (OL) indicates overload on the

30 seconds.

25

Integration Time (Settling Time): 1 minute when measuring a short impulse. 5 seconds when integrating a constant input signal. Accuracy: Within 0.7 dB at 25oC; Within 1.0 dB over the temperature range of -10oC to +50oC. Temperature Range: Operation Temperature Range: -10oC to +50oC. Accuracy over the Operation Temperature is within +/- 0.5 dB. Storage Temperature Range (less batteries): -20oC to +60oC Do not exceed the Storage Temperature Range because possible damage to the unit may result. Operating Humidity: Over a range of 30 to 90% relative humidity, the accuracy is within +/- 0.5 dB. Do not exceed 95% relative humidity because possible damage to the unit may result.

VII.

INTRODUCTION TO THE MODEL OB-100

The Quest Model OB-100 Octave Filter is a plug-in module containing a selectable set of filters. The OB-100 meets the most stringent requirements of ANSI S1.11-1986 and IEC R225-1966 for octave band filters. The unit contains ten selectable filter ranges from 31.5 Hz to 16 kHz center frequencies with full octave band width. Primary uses include frequency analysis for product noise emission, material acoustics, community noise, audiometer calibration and analysis of audiometric rooms. Active filters are employed throughout the Model OB-100, thus permitting the unit to have both high accuracy and compact size. VIII. ABOUT THE FILTER A. Filter Controls

Effect of Magnetic Fields: A magnetic field of 1 Oersted (80A/m) at 60Hz produces a maximum reading of 40 dB on Linear Weighting.

POWER Switch

Effect of Electrostatic Fields:

A three position slide switch that does the following:

Negligible.

Batteries: Two 9-volt alkaline batteries (NEDA 1604A) will provide approximately 20 hours of continuous operation. (10 hours with optional filter set.)

OFF -- Disconnects the filter circuitry from the attached sound level meter. With this switch in the off position, the OB-100 does not use power from the meter batteries.

Tripod Mount: A threaded insert on back of the meter accepts a standard 1/4-20 tripod mounting screw.

MANUAL -- Filter frequency selection is performed with two push buttons (START Buttons).

Size: 3.3 x 8.2 x 1.8 inches (84 x 208 x 47mm) not including the height of the preamp.

AUTO -- Unit automatically cycles through the desired filter frequencies while storing sample information for each frequency during the RUN mode.

Weight:

24 oz. (680g) including the preamp and batteries. START Buttons Allow the user to cycle through the different bandpass filters. The two buttons allow manual frequency control (in MANUAL Mode) or frequency direction control (in AUTO Mode). -20 dB Button When this button is depressed, the output of the filter is amplified by exactly 10 times (20 dB) and then fed back to the sound level meter. Therefore, 20 dB has to be subtracted from the meter reading when using this button. TIME A screwdriver adjustment to control the automatic cycle time filter frequency from approximately 5 to 30 seconds.

26

of each

27

B. Filter Connector

1.

Read the calibrator 1 kHz output level. Set the meter dB RANGE switch so that the calibrator level will indicate within the upper 20 dB of the meter display. Set the RESPONSE switch to FAST, WEIGHTING switch to LIN and MODE switch to SPL. Turn the POWER switch to ON.

2.

Set the OB-100 POWER switch to MANUAL and press the RUN button to place the meter into the RUN mode. Then use the two direction buttons to select the 1 kHz filter.

3.

Place the calibrator and adapter onto the microphone. Turn the calibrator ON. A meter reading that is very close to the level listed on the calibrator should result. An error of +/- 0.5 dB is acceptable. This is due to the center frequency filter tolerance of +/- 0.5 dB maximum.

4.

Change the OB-100 filter frequency first to 500 and read the display. Then change to 2k and read the display. At both frequencies the readings should be 19 to 23 dB less than the 1 kHz calibrator level.

5.

Change the OB-100 filter frequency to 1k and the meter dB RANGE so that the meter reads 20 to 40 dB less than full scale. Press and hold the -20 dB button on the OB-100. The meter reading shall rise approximately 20 dB to verify that the -20 dB button functions.

6.

Remove the calibrator.

The 30 pin connector on the top of the filter is used for connecting the filter to the sound level meter. Figure 19 shows the pinout for the filter connector. I X . GENERAL OPERATING PROCEDURE The Model 2800-100 O c t a v e B a n d Analyzer is made up of the Model 2800 Impulse Integratin g Sound L e v e l Meter and the OB-100 O c t a v e F i l t e r Set. The Figure 19 OB-100 External Filter Connector two units (Located on Meter Bottom) a r e connected together with the long captive screw provided with the filter box. General Operating Considerations for the Model 2800 (Section IV) basically the same when using the Model OB-100 with the meter.

The analyzer is now ready to use.

B. Taking a Measurement 1.

Turn the meter POWER switch ON. The meter will come on in the Pause mode. Perform a BATTERY test to verify that the analyzer has sufficient battery power. Replace the batteries if the bar indicator falls below the indicating arrow (located at 5 on the 0 - 60 scale).

2.

Set the dB RANGE switch to 80 - 140 dB. Set the RESPONSE switch to FAST, WEIGHTING switch to LIN (see note below), and the MODE switch to SPL.

The are

A. Operational Check The Model 2800 should be calibrated as outlined in the meter section of the manual (Section III, B, Calibration) while the OB-100 is OFF. The OB-100 has a fixed input to output voltage ratio of approximately 1 (0 dB) at each center frequency and requires no adjustment. After the meter is calibrated, check the filter for proper operation as follows:

NOTE:

3.

28

Note that the filter response can be in series with either A, B, C, or LIN. This is the operator's choice. However, LIN is generally used when taking octave band measurements. Turn the OB-100 POWER switch to MANUAL to activate the filter. "--" will appear in the display with the meter in the Pause mode.

29

4.

Select the desired WEIGHTING and RESPONSE. Then change the dB RANGE switch down in 20 dB steps until the OL indicator flashes or stays on. Then go back up 20 dB so that the OL indicator stays off. This ensures that the AC input to the filter is at its maximum voltage without clipping (overloading). MANUAL Filter Operation

Place the meter into the Pause mode using the RUN/Pause button. Press RESET to clear all internal memory. Select the first frequency of interest. Then enter the RUN mode for the required amount of time necessary to obtain a valid sample. Then enter the Pause mode, change to the next frequency of interest and enter RUN again, etc. Repeat this process for all frequencies of interest. AUTO Filter Operation Place the meter into the Pause mode using the RUN/Pause button. Press RESET to clear all internal memory. Select the first frequency of interest. (Be sure that the TIME adjustment is set to the desired filter cycle time.) Slide the filter POWER switch to AUTO. To start the sampling sequence, place the meter into the RUN mode and immediately press the proper direction button. (The UP ARROW button causes the frequency to cycle to the next higher frequency, the DOWN ARROW button causes the frequency to cycle to the next lower frequency.) When the last frequency of interest has completed its cycle time, slide the filter POWER switch to MANUAL and immediately place the meter into the Pause mode. NOTE:

30

C. Reviewing the Data To review the data, the meter must be in the Pause mode. Use the Up/Down buttons on the filter to review the frequencies that were measured. Each frequency has the following information in memory: SPL, MAX, MIN, SEL, TIME and LEQ. If an overload occurred during any frequency band measurements, the OL indicator will appear in the display. OL time can then be recalled by first placing the mode switch into the TIME mode and then holding the BATTERY button down. NOTE:

X.

Any frequencies that were not measured will appear as "---" in the display when the MODE switch selects either SPL, MAX, MIN, SEL and LEQ. Both TIME and OL TIME will appear as "0:00" since no run time has elapsed.

TECHNICAL INFORMATION

The OB-100 conforms to ANSI S1.11-1986, Order 3, Type 2, Sub-type C and IEC R225-1966. The normalized passband characteristic of a typical octave filter response is depicted in Figure 20. The OB-100 filter is flat within 0.5 dB in the passband, with the 3 dB down points at approximately .707 fc and 1.414 fc where fc is the center frequency of the band chosen. The fc/2 and 2fc frequencies are down by approximately 21 dB with the decade points (fc/10 and 10fc) down by greater than 70 dB. The block diagram of the OB-100 illustrated in Figure 21 traces the signal input from the Model 2800 through the filters and back to the sound level meter.

If it is necessary to record all 10 frequency bands, exit the AUTO mode while in the last frequency band. Use the MANUAL Filter Operation to obtain the last frequency. Otherwise, the first frequency will be written over.

31

X I . SPECIFICAT IONS Stand ards: ANSI S1.11 -1986 , Order 3 , Type 2 , Sub-t ype C a n d I E C Figure 20. R2251966.

Typical OB-100 Filter Response

Center Frequencies: 10 frequencies from 31.5 Hz to 16 kHz. Frequency Selection: Full manual stepping through each frequency.

control

or

automatic

sequential

Power Source: Sound Level Meter. Figure 21.

Block Diagram Model OB-100 Octave Filter

Size: 3.3 x 2.8 x 1.8 inches (84 x 71 x 47mm) Weight: 6 ounces (170 grams)

32

33

XII.

INTRODUCTION TO THE MODEL OB-300

The Quest Model OB-300 1/3 - 1/1 Octave Filter is a plug-in module containing a selectable set of filters. The OB-300 meets the most stringent requirements of ANSI S1.11-1986 and IEC R225-1966 for octave and third octave band filters. The unit contains 33 selectable filter frequencies from 12.5 Hz to 20 kHz when in the 1/3 mode and 11 selectable filter frequencies from 16 Hz to 16 kHz when in the 1/1 mode. It may be operated in either the manual or automatic mode. Primary uses include frequency analysis for product noise emission, material acoustics, community noise, audiometer calibration and analysis of audiometric rooms. Active filters are employed throughout the Model OB-300, thus permitting the unit to have both high accuracy and compact size.

MODE Switch Selects either the 1/3 octave filter set (33 frequencies) or the 1/1 octave filter set (11 frequencies). TIME A screwdriver adjustment to control the automatic cycle time of each filter frequency from approximately 5 to 30 seconds. B. Filter Connector The 30 pin connector on the top of the filter is used for connecting the filter to the sound level meter. Figure 22 shows the pinout for the filter connector.

XIII. ABOUT THE FILTER A. Filter Controls POWER Switch A three position slide switch that does the following: OFF -- Disconnects the filter circuitry from the attached sound level meter. With this switch in the off position, the OB-300 does not use any power from the meter batteries. MANUAL -- Filter frequency selection is performed with two push buttons (START Buttons). AUTO -- Unit automatically cycles through the desired filter frequencies storing sample information for each frequency during the RUN mode. START Buttons Allow the user to cycle through the different bandpass filters. The two buttons allow manual frequency control (in the MANUAL Mode) or frequency directional control (in the AUTO Mode). -20 dB Button When this button is depressed, the output of the filter is amplified by exactly 10 times (20 dB) and then fed back to the sound level meter. Therefore, 20 dB has to be subtracted from the meter reading when using this button.

34

X I V . GENERAL OPERATING PROCEDURE The Model 2800-300 O c t a v e B a n d Analyzer is made up of the Model 2800 Impulse Integratin g Sound L e v e l Meter and the OB-300 1/3 - 1/1 O c t a v e F i l t e r Figure 22. OB-300 External Filter Connector (Located on Top of Set. The Filter) two units a r e connected together with the long captive screw provided with the filter. The General Operating Considerations for the Model 2800 are basically the same when using the Model OB-300 with the meter.

35

A. Operational Check

NOTE:

The Model 2800 should be calibrated as outlined in Section III of the meter section (Checking the Meter Integrity, B. Calibration) while the OB-300 is OFF. The OB-300 has a fixed input to output voltage ratio of approximately 1 (0 dB) at each center frequency and requires no adjustment. After the meter is calibrated, check the filter for proper operation as follows:

3.

Turn the OB-300 POWER switch to MANUAL to activate the filter. "--" will appear in the display with the meter in the Pause mode. Select either 1/3 or 1/1 filters using the MODE switch.

4.

Select the desired WEIGHTING and RESPONSE. Then change the dB RANGE switch down in 20 dB steps until the OL indicator flashes or stays on. Then go back up 20 dB so that the OL indicator stays off. This ensures that the AC input to the filter is at its maximum voltage without clipping (overloading).

1.

Read the calibrator 1 kHz output level. Set the meter dB RANGE switch so that the calibrator level will indicate within the upper 20 dB of the meter display. Set the RESPONSE switch to FAST, WEIGHTING switch to LIN and MODE switch to SPL. Turn the POWER switch to ON.

2.

Set the OB-300 POWER switch to MANUAL and the MODE switch to 1/1. Press the RUN button to place the meter into the RUN mode. Then use the two direction buttons to select the 1 kHz filter.

3.

Place the calibrator and adapter onto the microphone. Turn the calibrator ON. A meter reading that is very close to the level listed on the calibrator should result. An error of +/- 0.5 dB is acceptable. This is due to the center frequency filter tolerance of +/- 0.5 dB maximum.

4.

Change the OB-300 filter frequency first to 500 and read the display. Then change to 2k and read the display. At both frequencies the readings should be 19 to 23 dB less than the 1 kHz calibrator level.

5.

Change the OB-300 filter frequency to 1k and the meter dB RANGE so that the meter reads 20 to 40 dB less than full scale. Press and hold the -20 dB button on the OB-100. The meter reading shall rise approximately 20 dB to verify that the -20 dB button functions.

6.

Remove the calibrator.

The analyzer is now ready to use.

B. Taking a Measurement

36

1.

Turn the meter POWER switch ON. The meter will come on in the Pause mode. Perform a BATTERY test to verify that the analyzer has sufficient battery power. Replace the batteries if the bar indicator falls below the indicating arrow (located at 5 on the 0 - 60 scale).

2.

Set the dB RANGE switch to 80 - 140 dB. Set the RESPONSE switch to FAST, WEIGHTING switch to LIN (see note), and the MODE switch to SPL.

Note that the filter response can be in series with either A, B, C, or LIN. This is the operator's choice. However, LIN is generally used when taking octave band measurements.

MANUAL Filter Operation Place the meter into the Pause mode using the RUN/Pause button. Press RESET to clear all internal memory. Select the first frequency of interest. Then enter the RUN mode for the required amount of time necessary to obtain a valid sample. Then enter the Pause mode, change to the next frequency of interest and enter RUN again, etc. Repeat this process for all frequencies of interest. Note that it is not necessary to enter the pause mode between each frequency if the user just wishes to step through the frequencies sequentially with no delay time in between frequencies. AUTO Filter Operation Place the meter into the Pause mode using the RUN/Pause button. Press RESET to clear all internal memory. Select the first frequency of interest. (Be sure that the TIME adjustment is set to the desired filter cycle time.) Slide the filter POWER switch to AUTO. To start the sampling sequence, place the meter into the RUN mode and immediately press the proper direction button. (The UP ARROW button causes the frequency to cycle to the next higher frequency, the DOWN ARROW button causes the frequency to cycle to the next lower frequency.)

37
