SciSpin MICRO Operating Manual Ver Dec 2011

USER MANUAL

Contents Copyright... 3 Safety Reminder... 4 1. Specifications...6 2. Declaration of Conformity...6 3. Required Operation Conditions...7 4. Installation...7 4.1 Location...7 4.2 Connection of the Power Cord and Grounding...7 5. Structure...8 6. Operation Panel...9 7. Rotor Preparation...10 7.1 Prepare the Sample...10 7.2 Inject the Sample into Tubes...10 7.3 Keep the Tubes Balance...10 7.4 Inspect the Rotor...10 7.5 Symmetrically Load Centrifuge Tubes to Rotor...10 8. Operation...11 8.1 Normal Operation...11 8.2 RCF Operation...13 8.3 Pulse Operation...14 9. Maintenance...14 10. Troubleshooting...15 10.1 Possible Problems and Solutions...15 10.2 How to Open the Door...15 11. Instructions for the Rotor and Tubes...16 11.1 Rotor Instructions...16 11.2 Tubes...17 12. Calculate RCF...18 13. Ordering Information ...18 14. Warranty...19 14.1 Warranty of the Centrifuge...19 14.2 Warranty of the Rotor...19 15. After-sales Service...19

Page 2

High Speed Mini Micro-Centrifuge

Copyright: No part of this manual may be reproduced or transmitted without prior written permission of us. We can not be responsible to inform at real-time if the outline and specifications of centrifuge are subject to change for improvement. VERSION201112

Page 3

USER MANUAL

Safety Reminder Common safety precautions Carefully read the following safety precautions for a thorough understanding. ● Follow the instructions and procedures described in this manual to operate this centrifuge safely. ● Carefully read all safety messages in this manual and the safety instructions on the centrifuge. ● Safety messages are labeled as indicated below. They are in combination with signal words of “WARNING” and “CAUTION” with the safety alert symbol to call your attention to items or operations that could be dangerous to you or other persons using this centrifuge. The definitions of signal words are as follows: ！ WARNING: Personal Danger

Warning notes indicate any condition or practice, which if not strictly observed, could result in personal injury or possible death. ！ CAUTION:Possible damage to centrifuge

Caution notes indicate any condition or practice, which if not strictly observed or remedied, could result in damage or destruction of the centrifuge. NOTE:Notes indicate an area or subject of special merit, emphasizing either the product’s capability or common errors in operation or maintenance. ● Do not operate this centrifuge in any manner not described in this User manual. When in doubt or have any troubles with this centrifuge, ASK FOR HELP. ● The precautions described in this User manual are carefully developed in an attempt to cover all the possible risks. However, it is also important that you are alert for unexpected incidents. Be careful operating this centrifuge.

！WARNING ● This centrifuge is not explosion-proof. Never use explosive or flammable samples. ● Do not install the centrifuge in or near places where inflammable gases are generated or chemicals are stored. ● Do not place dangerous materials within 30cm around the centrifuge. ● Prepare all necessary safety measures before using samples that are toxic, radioactive or contaminated with pathogenic micro-organisms. Use of these is at your own responsibility. ● If the centrifuge, rotor and accessories that have been contaminated by solutions with toxic, radioactive or pathogenic materials, clean it according to the decontamination procedure as specified. ● If you require service at site, please sterilize and decontaminate the centrifuge in advance, and then notify the service center the details of the materials and procedure. ● To avoid electrical shocks, insure hands are dry before handling the power cord or turn on/off the power switch. ● For safety purposes, do not enter within 30cm around this centrifuge when it is in operation. ● While the rotor is rotating, never release the door lock. Unauthorized repairs, disassembly or modifying the centrifuge except by our service center are strictly prohibited.

Page 4

High Speed Mini Micro-Centrifuge

！ CAUTION ● This centrifuge must be located on a firm and level table. ● Make sure the centrifuge is horizontal before running. ● Make sure the angle between the door and cover is greater than 70 degrees when opening the door. ● Be careful not put your fingers or hands between the door and cover while the door is open. ● Do not move or relocate the centrifuge when it is running. ● If fluid spills in the rotor chamber, please promptly clean and dry with a dry cloth to avoid sample contamination. ● Ensure to remove any objects and fragments of the tubes dropped inside the rotor chamber before running the centrifuge. ● Cautions with rotor (1) Always check for corrosion and damages on the rotor surface before using it. Do not use the rotor if an abnormality is found. (2) Do not set the speed beyond the allowable minimum speed of the rotor kits (rotor or adapters). Make sure to run it below the allowable minimum speed. (3) Do not exceed the allowable imbalance. (4) Use the rotor and tubes within their actual capacities. (5) If the rotor is attached with a lid, ensure it is tightened before operation. ● If any abnormal condition occurs during operation, please stop it immediately and contact our service center. Notify the service center is a warning code if displayed. ● Vibrations are likely to damage the centrifuge, contact our service center if abnormality observed.

Page 5

USER MANUAL

1. Specifications Maximum speed Maximum RCF Maximum capacity Timer Acceleration/ Braking time Noise level Driving Motor Safety devices Power requirements Dimensions(mm) Weight Additional features

15000rpm, increment: 100rpm 15100×g, increment: 100×g 2ml×12 30 seconds -99 minutes-HOLD, continuous operation 28 s / 28 s (with aluminum alloy rotor) 11 s / 9 s (with plastic rotor) 56 dB (with aluminum alloy rotor) 54 dB (with plastic rotor) Brushless DC motor Door interlock; Over-speed detector; Over-temperature detector; Automatic internal diagnosis Single-phase, 110V-240V, 50Hz/60Hz, 3A (L)255×(W)245×(H)140 6kgs Speed/RCF switch; Pulse operation; Processing display; Voice reminder

2. Declaration of Conformity With aluminum alloy rotor: Construction in accordance with the following safety standards: EN 61010-1 Construction in accordance with the following EMC standards: EN 61326-1/ FCC Part 15 Subpart B/ IECS 001 Associated EU guidelines: EMC-guidelines: 2004/108/EC Centrifuge guidelines: 2006/95/EC This ISM device complies with Canadian ICES-001. Cet appareil ISM est conforme à la norme NMB-001 du Canada. With plastic rotor: Construction in accordance with the following safety standards: EN 61010-1 EN 61010-2-20 Construction in accordance with the following EMC standards: EN 61326-1/ FCC Part 15 Subpart B/ IECS 001 Associated EU guidelines: EMC-guidelines: 2004/108/EC Centrifuge guidelines: 2006/95/EC This ISM device complies with Canadian ICES-001. Cet appareil ISM est conforme à la norme NMB-001 du Canada. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This centrifuge has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the centrifuge is operated in a commercial environment. The centrifuge generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the user manual, may cause harmful interference to radio communications. Operation of centrifuge in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference. Page 6

High Speed Mini Micro-Centrifuge

3. Required Operation Conditions 3.1 Basic operation Conditions (1) Power: 110V-240V, 50Hz/60Hz, 3A. (2) Ambient temperature: 2℃~40℃. (3) Relative humidity: ≤80%. (4) No vibration and airflow around. (5) No electric dust, explosive and corrosive gases around.

3.2 Transport and storage conditions (1) Storage temperature: -40℃~55℃. (2) Relative humidity: ≤93%.

4. Installation This section describes the instructions that you should abide when install the centrifuge to ensure your safety and the optimum performance. Before moving the centrifuge, the rotor must be removed.

！WARNING ● Improper power supply may damage centrifuge. ● Make sure the power source conforms to the required power supply before connecting.

4.1 Location (1) Place the centrifuge on a firm、flat and level surface, ensure the four feet of this centrifuge stand on the counter firmly. Avoid installing on the slippery surface or surface prone to vibration. (2) Ideal ambient temperature is 20℃±5℃, avoid placing the centrifuge in direct sunlight if temperature exceeds 30℃. (3) Keep clear of the centrifuge at least 10cm on both sides and at least 30cm behind it to guarantee the cooling efficiency. (4) Keep away from heat or water to avoid sample temperature issues or centrifuge failures.

4.2 Connection of the power cord and grounding

！WARNING ● To avoid electrical shocks, ensure your hands are dry when touching the power cord. ● This centrifuge must be grounded properly. A minimum 10A outlet providing a sufficient ground is required, and this must meet local safety requirements.

Page 7

USER MANUAL

5. Structure

Door lock hook

Rotor

LCD Display Door release hole

Operation panel

Foot

Figure 5.1 Front view of centrifuge

View

Door

Air vents Power inlet

Power switch

Figure 5.2 Rear view of centrifuge

Page 8

High Speed Mini Micro-Centrifuge

6. Operation Panel

SELECT

（1）

PULSE

（2）

DOOR

（3）

（4）

START/STOP

（5）

Figure 6-1 Operation panel

Item Symbol

Name

Function

1

Select

Select button

Press the button to choose the program which you want to modify.

2

Pulse

Pulse button

The speed can be accelerated and held at the set speed when pressing Pulse on.

Program button

Clockwise rotate to increase program values. Rotate anti-clockwise to decrease program values. Press the button, shift between speed and RCF display.

3 4

Door

Open/ lock button

Press the button to open the door. The button is not available when the centrifuge is running.

5

START STOP

Start/ Stop button

Press the button to start running. The centrifuge will brake to stop running if pressed during centrifugation.

Speed area

Door status

×100rpm

Time area

min

Figure 6-2 The main interface

Main interface is as figure 6-2. The speed is set to be 15000 rpm, running time is 12 minutes. When speed symbol is rotating, indicating the centrifuge is running. Time display symbol displays the ratio of working to time setting. The total time setting is divided into 10 sections.

Page 9

USER MANUAL

7. Rotor Preparation 7.1 Prepare the samples 7.2 Inject the samples into tubes

！CAUTION

● Do not overload samples into the centrifuge which will cause leaking. ●Do not exceed the actual capacity allowed in the user manual.

7.3 Keep the tubes balance ●Although the centrifuge can accept sample balancing by eye, we recommend that you keep this centrifuge in a wellbalanced condition to extend its life expectancy. ●Never intentionally run the centrifuge under unbalanced condition even though the allowable imbalance is not exceeded.

7.4 Inspect the rotor Check the rotor for corrosion or scratches before using.

！CAUTION ● Any abnormality such as corrosion or scratches are found, stop using the rotor and contact our service center. ● Only manufacturer’s rotors must be used with the unit.

7.5 Symmetrically load centrifuge tubes to rotor ● Make sure the rotor lid is securely fixed on the rotor, as well as the rotor and shaft are tightened. Otherwise, the rotor may be moved off while rotating and cause damages of the centrifuge and rotor.

Page 10

High Speed Mini Micro-Centrifuge

8. Operation ！CAUTION

● Do not push or lean against the centrifuge while it is running. ● Do not run the centrifuge when fragments or sample solutions are left in the centrifuge chamber. Always keep the centrifugal chamber clean. ● If the centrifuge makes strange noise during operation, stop it immediately and contact our service center. Notify them of the warning code if displayed.

8.1 Normal operation Turn on the power switch, centrifuge will display the running interface last time after passing the self-diagnostic checks, see figure 8-1 below:

Speed area

Door status

Time area

×100rpm

min

Figure 8-1 The last running interface

● Speed: 15000rpm. Running time: 12 minutes. ● The door lock is released.

8.1.1 Rotor loading and removal

！CAUTION ●Attach the rotor to the rotor shaft. Ensure the rotor is in position and connected with the shaft, tightening the locking nut to secure the rotor with shaft, to prevent the rotor damaging the centrifuge. ●Ensure the rotor lid is firmly tightened to the rotor.

Page 11

USER MANUAL

Keyway

Align the keyway position of shaft when loading rotor

Locking nut

Fastener Rotor lid

Load the rotor to the shaft

Symmetrically load centrifuge tubes to rotor

Load the rotor lid

Figure 8-2 The rotor installation

● Load the rotor to the shaft to ensure rotor is in position until it connected well with the shaft. ● Rotate the rotor slightly with your fingers to check. if the rotor vibrates, if so attach the rotor again. ● Hold on the rotor with one hand, tighten clockwise the nut with the other hand and make sure tighten firmly. ● Put the rotor lid to the rotor, press the fastener down and make the fastener attach the locking nut tightly. ● Close the door and start running. ● To release the rotor, firstly pull the fastener up to remove the lid, and then turn the locking nut anti-clockwise.

！CAUTION

● Check the rotor is firmly tightened before running.

8.1.2

Set the operation programs

Press the Select button to select required program. The value can be modified when the program is flashing. Rotate the program button clockwise to increase value; anti-clockwise rotate the program button to decrease value. Program button rotate faster, and the value increase faster. The minimum speed increment is 100 rpm, the minimum time increment is 1 second. (1) Set the speed ● Press the select button Select until the speed rpm is displayed. ● When the speed button is selected, the speed symbol will flash the speed value. ● The minimum speed value you can set 500 rpm, the minimum increment is 100 rpm. ● Rotate program button clockwise to increase speed value; rotate the program button anti-clockwise decrease speed value. ● You can speed-up set the speed value by rotating program button quickly. ● There is a circulating function to increase/decrease the speed values. Rotate the program button clockwise change settings from small → large → maximum → minimum. Rotate the program button anti-clockwise change settings from large → small → minimum → maximum.

Page 12

to

to to

High Speed Mini Micro-Centrifuge

(2) Set the time ● Press button Select , time value flashes in the time setting mode. ● Rotate the program button to set running time from 30 seconds to 99 minutes. ● When the time displays HD, this is a continuous running mode.

8.1.3 Start the operation (1) Press button START to start running STOP ● Timer will operate once the speed setting value is reached, the screen displays the remaining run time. (2) View and modify the operation programs ● Pressing button Select returns the display to the program interface and displays setting programs. Press the select button Select to the desired program. When flashing, rotate parameter button to modify values. Release the button after 5 seconds, and the centrifuge will return to normal operation mode and run according to the new value. ● If the set time value has been modified, the operation time is not affected and will continue. (3) Warning display ● If an error occurs during the operation, the centrifuge will brake to stop automatically, and display the error code on the time/display area. The error code can be checked in the table 10-1, and corrective actions can be applied accordingly.

8.1.4 End the operation (1) The centrifuge will brake when it reaches the setting time or START button is pressed. STOP ● When the rotor stops rotating, the centrifuge will start beeping to alert the operation has finished. (2) Open the door ●The door can be released automatically when the operation has stopped. ●With the door closed, you are able to press the Door button to open it. ●After ending the operation, the program will store the setting parameters of this operation, and will recall these parameters when restarting the program. (3) Open the door and take out the rotor and samples.

8.2 RCF operation (1) Turn on the power switch (2) Set a RCF (Relative Centrifugal Force) value ●Press the select button Select and choose speed unit ×g, the speed symbol will flash into RCF value input status. ●If no button is pressed after the speed value has flashed for 5 seconds, the input mode will be shut down. ●Rotate program button to input a RCF value, RCF increment is100×g. (3) Set operating conditions The other operation, please refer to the section 8.1.

Page 13

USER MANUAL

8.3 Pulse operation This function is used to remove the residual samples adhered to the interior of the tubes or for quick spins. Note:The button works only while the rotor stopped and the door is locked. (1) Turn on the power switch and load the rotor to the shaft, tighten the rotor lid and make sure it is in secured position, and then close the door. (2) The centrifuge gets into preparation mode and displays last running values.The values can be reset. (3) Press Pulse knob and hold, the centrifuge will speed up to the setting speed. While releasing Pulse knob during acceleration, the centrifuge will start to decelerate and stop.

9. Maintenance ！CAUTION ● If do not follow the recommended instructions for cleaning or disinfecting may damage the centrifuge. (1) Centrifuge ● If the centrifuge is exposed to ultraviolet rays for a long time, the color of the door may be changed or the label may be came off. After using, cover the centrifuge with a piece of cloth to protect it from direct exposure. ● If the centrifuge needs cleaning, clean it with a cloth or sponge moistened with a neutral detergent solution. ● Sterilize the centrifuge by wiping with a cloth moistened with 70% ethanol solution. (2) Rotor chamber

！CAUTION ● Do not directly pour water, neutral detergent or disinfectant solution into the rotor chamber, otherwise fluids may leak into the drive units and cause corrosion or deterioration to the bearings. ● If the rotor chamber needs cleaning, clean with cloth or sponge moistened with a neutral detergent solution. Sterilize the centrifuge by wiping with a cloth moistened with 70% ethanol solution. (3) Drive shaft ● We recommend regular maintenance for drive shaft. You can wipe the drive shaft with soft cloth, and then apply a thin coat of silicon grease. (4) Door ● Clean and sterilize the door using the same method as the section(1)above. (5) Rotor ● To prevent corrosion, remove the rotor from rotor chamber. If not in use for a lone term, then detach the rotor lid and turn upside down to dry the tube holes and keep clean. ● For sample leaks in the rotor, rinse the rotor with water. Apply a thin coat of silicon grease to the rotor when it is completely dry. ● The rotor should be checked every 3 months to ensure the tube and rotor holes keep are clean and apply a thin coat of silicon grease.

Page 14

High Speed Mini Micro-Centrifuge

10. Troubleshooting 10.1 Possible problems and solutions This centrifuge has a self-diagnostic function. If a problem occurs, an error/warning code will be displayed on the time display screen and the operator can determine the malfunction with the warning code below. Symptom

Causes

•Building power circuit breaker trips. Nothing appears on the screen when the •The fuse was blown out. power is turned on. •Rotor do not match with shaft •Samples are imbalance •Rotor lid loosed

Abnormal vibration

Alarm code appeared on the time display screen

Solutions •Remove the trouble and turn on the power. •Replace the fuse. •Install again the rotor •Weighting scales, install symmetrically •Tighten the rotor lid firmly

•The door opened during running. •Close the door immediately. •Press the button while the door is •Close the door and then start to operate. opening. •The setting speed exceed the allowable E-06 •Modify the speed value. Set wrong speed range. E-10～86 •Read the service manual •Contact with service center E-02 Door fault

Table 10-1 Possible problems and solutions ●Warning code E-1～E-9 are related to wrong operating. You can continue running the centrifuge after the cause removed.

10.2 How to open the door 10.2.1 In the case of power on

！CAUTION ● The door just can be opened while the power is on and rotor stops rotating. (1) Turn on the power switch, release the door automatically. (2) The door will be released automatically once the operation is finished. (3) It is available to release the door by pressing button Door once the rotor stops. 10.2.2 In the case of power outage The door cannot be opened automatically if there is a power outage. It is available to be opened manually as follows. (1) Ensure if the rotor has stopped rotating. ● Listen carefully to ensure no rotating sound can be heard. (2) Insert a screw driver into the hole to open the door. ● Hole is located on the top right side of the unit. ● Insert a screw driver into the hole and push forward to release the door.

Page 15

USER MANUAL

11. Instructions for the Rotor and Tubes ！CAUTION

● Read the user manual thoroughly to properly load and use rotor. ● Do not exceed the allowable maximum speed of rotor、tube and adapters etc.. Ensure the allowable maximum speed of adapters is lower than the rotor’s maximum speed.

11.1 Rotor instructions 11.1.1 Rotor structure Locking nut

Fastener

Rotor block

Rotor lid

Shaft

Tube holes

Figure11-1 The rotor structure 11.1.2 Available rotors and adapters Table 11.1 Rotors and adapters Model

Rotor type

ID code

with aluminum A12-2 alloy rotor with plastic rotor

Tubes

Adapters

1.5/2.0ml tube 01

！CAUTION

02

Maximum RCF (×g)

15000

15100

0.2ml PCR tube

A02P2

15000

11700

0.5ml micro tube

A05P2

15000

12780

15000

15100

1.5/2.0ml tube A12-2P

Maximum speed (rpm)

0.2ml PCR tube

A05P2

15000

11700

0.5ml micro tube

A02P2

15000

12780

Allowable imbalance(*) Volume Imbalance imbalance(**) 2.0g/ tube

5mm/ tube

2.0g/ tube

5mm/ tube

●Aluminum alloy rotor and plastic rotor cannot be exchanged between different models.

Page 16

High Speed Mini Micro-Centrifuge

11.1.3 Notice The centrifuge rotor can separate samples which density lower than 2.0 g/ml. If the separated samples density is over 2.0 g/ml, please calculate allowable speed depending on the following formula. Allow Speed (rpm) = Maximum speed × (2.0 (g/ml) /Sample density (g/ml) )1/2 11.1.4 Autoclaving A12-2 rotor is manufactured in high-strength aluminum alloy material and can be autoclaved: 121oC (1.0kg/cm2), 20 minutes. A12-2P rotor is made of plastic, cannot be high-pressure sterilization and UV irradiation, only ordinary sterilization can be used.

！CAUTION ● The lid of the rotor is made of plastic, can not be high-pressure sterilization, only ordinary sterilization can be used.

11.2 Tubes 11.2.1 Cleaning and sterilizing tubes Table 11.2 Cleaning and sterilizing conditions for tubes

O:Applicable X:Inapplicable Materials

Conditions

Cleaning

Cleaning fluids

Ultrasonic cleaning Autoclaving Sterilization

Boiling Ultraviolet sterilization Gas sterilization

Acidic(pH5 or lower) Acidic(higher than pH5 ) Alkaline(higher than pH9 ) Alkaline(pH9 or lower) Neutral(pH7) Warm water(up to 70℃) Neutral detergent(pH7) 115℃(0.7kg/cm2)30minutes 121℃(1.0kg/cm2)20 minutes 126℃(1.4kg/cm2)15 minutes 15 to 30 minutes 200-300nm Ethylene oxide Formaldehyde

PA

PC

PP

X O O O O O O O X X O X O O

X O X O O O O O O X O X X O

X O O O O O O O O X O X O O

PA:Polyallomer; PC:Polycarbonate; PP:Polypropylene 11.2.2 Cleaning PC tubes PC material is low in chemical resistance against alkaline solutions. Avoid using neutral detergents with pH higher than 9. Note that pH of some neutral detergents are still higher than 9 even if diluted according to the the manufacturer’s instruction. Use detergent with its pH between 7 and 9.

Page 17

USER MANUAL

11.2.3 Autoclaving PA、PC and PP tubes PA begins softening at about 120℃, PC and PP at about 130℃. Autoclave PA tubes at 115℃（0.7kg/cm2）for 30 minutes, PC and PP tubes at 121℃（0.1kg/cm2）for 20 minutes. If a certain temperature is exceeded, the tubes may be deformed. When use a sterilizing chamber, please operate as follows: (1)Place tubes in vertical position, mouths upward. If tubes are placed sideways, they may deform into an oval shapedue to gravity. (2)Remove locking nut and lid to prevent from deformation or rupture. (3)Wait until the sterilizing chamber cools down to the room temperature before removing tubes. 11.2.4 Conditions and life expectancy of tubes The life expectancy of plastic tubes depends on the characteristics of samples, speed of the rotor used, temperature applied and so on. When the plastic tubes are used for ordinary aqueous samples (pH between 5 and 9), their life expectancies are defined as follows. Be operated at the maximum speed: High quality tubes (PA、PC、PP): 30-50 operations Ordinary tubes (PA、PC、PP): around 10 operations(Using in low speed can extend the tube life) Life expectancy of tubes also depends on the pretreatment conditions such as cleaning and sterilization, lifetime can be cut down. Notice: Do not use damaged or cracked tubes.

12.Calculate RCF Relative Centrifuge Force (RCF) can be determined with the following calculation formula. RCF = 1.118 × r × n2 × 10-5 R - rotating radius, unit: cm; n - rotating speed, unit: rpm

13. Ordering Information Cat. No. *91101511xxxx *91111511xxxx *91121511xxxx *91131511xxxx *91101541xxxx *91111541xxxx *91121541xxxx *91131541xxxx Accessories 19400005 19400010 19500001 19500002

Model

Descriptions High Speed Mini Centrifuge, with A12-2 rotor kits, US plug, 100V-240V/50Hz/60Hz High Speed Mini Centrifuge, with A12-2 rotor kits, Cn plug, 100V-240V/50Hz/60Hz High Speed Mini Centrifuge, with A12-2 rotor kits, Euro plug, 100V-240V/50Hz/60Hz High Speed Mini Centrifuge, with A12-2 rotor kits, UK plug, 100V-240V/50Hz/60Hz High Speed Mini Centrifuge, with A12-2P rotor kits, US plug, 100V-240V/50Hz/60Hz High Speed Mini Centrifuge, with A12-2P rotor kits, Cn plug, 100V-240V/50Hz/60Hz High Speed Mini Centrifuge, with A12-2P rotor kits, Euro plug, 100V-240V/50Hz/60Hz High Speed Mini Centrifuge, with A12-2P rotor kits, UK plug, 100V-240V/50Hz/60Hz

A12-2 A12-2P A02P2 A05P2

Rotor kits with lid, fixing clips and O'ring, 15000rpm, 2ml*12, used with D2012 Rotor kits with lid, fixing clips and O'ring, 15000rpm, 2ml*12, used with D2012 plus 0.2ml rotor adapter, used with A12-2 & AS24-2 rotors, 24pcs/pk 0.5ml rotor adapter, used with A12-2 & AS24-2 rotors, 24pcs/pk

* The last four figures “xxxx” of Cat. No. can be provided by supplier.

Page 18

High Speed Mini Micro-Centrifuge

14. Warranty 14.1 Warranty of the centrifuge This centrifuge is guaranteed for two years from the date of delivery provided that it has been operated and maintained properly.

14.2 Warranty of the rotor The rotor is guaranteed for 5 years from the date of delivery upon manufacturer. Please pay attention, do not use the rotor once it has been corrosion or fatigue damage. The warranties of the centrifuge and the rotor become invalid in the case of the following conditions even if within the guarantee period expires: (1) Failures caused by incorrect installation. (2) Failures caused by rough or improper handling. (3) Failures caused by conveyance or relocation after installation. (4) Failures caused by unauthorized disassembly or modification. (5) Failures caused by using non-standard spare parts or accessories and unauthorized modification of the rotor or centrifuge. (6) Failures caused by natural disasters including fire, earthquakes and so on. (7) Consumables and parts have a limited guarantee period.

15. After-sales Service In order to ensure to operate centrifuge safely and efficiently, it is necessary for regular maintenance. If centrifuge has problems, do not attempt to repair it by yourself. Contact our sales or service center.
