CL mini BED 7 Instructions for Use Sept 2016

Compact - Laser Series CL mini

Instructions for use

Admitted Accessories: Lightning cable bent (Dental top) Power reducing tip Laser storage

Admitted Protection Goggles: Soft-Caps Laser goggles (=glasses for the patient) Mini-Soft-Caps Laser goggles for children Comfort Laser goggles (=glasses for the patient) Comfort Laser adjust glasses (=glasses for the therapist) Comfort Laser goggles for children

Admitted Device in connection with the CL mini Laser: Point Detector PS3, with Safety Connection Cable

0

Compact - Laser Series CL mini

Instructions for use

1 Description of the Compact Laser CL mini The CL mini is a soft - laser (Low Level Laser) which you can hold in your hand. It is powered by one standard battery (size AAA) or with one NiMH battery. The laser light is red and divergent, so that the device complies with the Laser Class 2M. The light at the slender tip is almost point-like, so you very well may irradiate punctiform. If you penetrate with a distance of a few centimeters between tip and skin, the irradiation is circular, wherein the diameter of the circle becomes larger with increasing distance. The irradiation time can be adjusted in two stages. In addition, it can also be selected manually as desired.

2 Intended Use and Indications The Intended Use of the Compact – Laser CL mini is: radiation of skin, mucous membrane and dental applications. It is a “Medical Product“ in accordance with the EU Medical Product Law and with the Essential Requirements 93/42 EWG and 2007/47 EC. This unit is approved by TGA.

  

The main applications are divided into the sections Accellerating of wound healing and improvement of local defense in the wound area,especially in older patients, diabetics and impaired wound healing, Reduction of pain, i.a. after trauma, surgery and chronic degenerative diseases, for Acupuncture (instead of needling).

1

Compact - Laser Series CL mini

Instructions for use

3 Safety precautions to be observed during the use of therapy lasers The appropriate legal security precautions are to be observed! Direct irradiation of the opened eye should be avoided at all costs! Irreparable damage can be expected!

       

  



With a power of over 10 mW even the closed eye should not be irradiated! During radiation to the face use Soft Caps!

Open wounds may NOT be touched with the laser or its accessory! Risk of infection! Upon insertion of the laser tip or of the accessory part "optical fiber bent" in body openings there is the risk of introducing contaminants into the body – danger of infection! When printing with the laser tip on non-intact skin or mucous membrane that could be pierced – danger of bodily injury and infection! Laser therapy should be conducted by trained personnel only (= according to the list of trained persons enrolled in the Instruments Book)! The use of the operating facilities or installation contingencies in any methods other than mentioned in these user instructions can lead to dangerous irradiation! CL mini- Laser must be used and stored within the following temperature range: Case Temperature: during use 10 to 40 oC (50 to 104 oF), Storage temp. 0 bis 50 oC (40 to 122 oF)! Caution is recommended during its transport by car in the summer! Permissible humidity: 30 till 95 %rel, The humidity should not condense on the case/body (no dew-drops)! Air pressure: not critically No modification of this equipment is allowed! Portable and mobile HF communication systems may interfere with this instrument! The use of inflammable anaesthetic gases or oxidized gases like nitrogen (N2O) and oxygen should be avoided. Some materials like cotton, that are saturated with oxygen, could be set on fire at these high temperatures, created at the because of the laser’s direction. Before the laser is put into operation, there should be a specific period for evaporation of solvents in adhesives and inflammable solvents, which are used for cleaning and disinfection. Attention should be drawn to the fact that the body’s gases too can set on fire. It is further recommended that: Therapy duration for babies being treated at the cranial region should be short (approx. 50%)!

2

Compact - Laser Series CL mini

Instructions for use

3.1 Alignment Laser Spectacles (Therapist’s Spectacles): At the use of lasers of the laser-protection-class 2M the therapist can wear the laser alignement spectacles as in accordance with the current edition of international standard EN208. Minimal specifications of these spectacles for the CL mini corresponding to EN208: Protection level at 658 nm: for CL mini 8: R 1 for all other CL mini lasers: R 2 and admitted for laser mode D (continuous operation)   

Silberbauer - laser alignment spectacles offer only protection against accidental irradiation through laser up to these levels! They are NOT ALLOWED to be used for the deliberate view of beam! They are only protection against casual irradiation, when the eye lid closure reflex is not suppressed or slowed down (medical treatment, illness ...); and thus repeated irradiations of the eye have to be reduced.

Attention! Colour identification is disturbed by the glasses! 

Clean glasses only with a glasses-cleaning-cloth or cloth and windows-detergent.

3.2 Laser Protection Spectacles (Patient’s Spectacles): The patient should wear laser-goggles. As per the international standard EN 207 in its current edition. Minimal Specification correspond to EN 207:

of

laser

protection

spectacles

Protection level at 658nm : L3; Laser mode: D (continuous operation)   

The Silberbauer laser protection spectacles offer only protection against accidental irradiation through laser up to these powers! They are NOT ALLOWED to be used for the deliberated view into the beam! They protect only then against casual irradiation, when the eye lid closure reflex is not suppressed or slowed down (medical treatment, illness ...); and thus repeated irradiations of the eye have to be reduced.

Attention! Colour identification is disturbed by the glasses! 

Clean glasses only with a glasses-cleaning-cloth or cloth and windows-detergent.

3

Compact - Laser Series CL mini

Instructions for use

3.3 Contraindications The laser treatment has a low risk only. Different authors have controversial positions because the laser is especially successful in applications where you for forensic reasons might have concerns. However, if no sufficient tests are available, some contraindications should be observed:

 

Direct irradiation of the open eye, it is essential to avoid!

In the area of open fontanelles or open skullcaps, as well as growth gaps in childhood and adolescence should not be irradiated.



During pregnancy, the penetration of the abdominal area is to be avoided. Attention! Sopme acupuncture points can trigger labour (Bl31, Bl32, Bl60, Bl67, Di4, Di5, Gbl21, Gbl34, LG20, MP6)

  

Endocrine organs may not be treated! For epileptics, the scalp region may not be treated.

In case of light dermatoses or higher photosensibility, it is not allowed to penetrate (for all kinds of dermatoses which react with formation of erythems or vesicles to small doses of light).



Pacemakers cannot be affected by penetration with the cw- laser, so there are no contraindications.



Too long therapy time does not give better results, but also no harmful side effects. Exceptions are penetrations in the scalp region (more minutes), which can cause headache, and daily penetration with high doses which can cause that pain comes again.



It is further recommended that: Therapy duration for babies being treated at the cranial region should be short (approx. 50%)!

4

Compact - Laser Series CL mini

Instructions for use

4 Compact - Laser CL mini : View 1

2

3

4

5

6 7 "Constant Power" Ser.Nr.: xxxx H

Compact - Laser

8

CL mini xx-658

9

1 Laser point 2 Light Emitting Diode, yellow 3 Push-button 4 Aluminium Body 5 Rotary switch

6 Type plate and details 7 Socket for Silberbauer Detector PS3 8 Battery Cap 9 Laser warning label

Point

4.1 Accessory Optic Fibre, bent: Direction of the Laser Beam

Power loss with optic fibre: 25 % almost! Power-reducing-tip: Direction of the Laser Beam

Transmission 50%: e.g.: for CL mini 30 – Output Power reduces to approx. 15 mW

4.2 Initial use The Silberbauer Compact - Laser mini is delivered with rechargable NiMH- Batteries in Size AAA and with a charger for these batteries and can be used also with Alkali-ManganBatteries, Type AAA. Open battery cap (8) at the end of the laser and insert battery with positive end pointing into the tube; close the cap and turn it clockwise until it stops. Now your Silberbauer Compact - Laser mini is ready to use!

5

Compact - Laser Series CL mini

Instructions for use

5 Use of the Compact – Lasers CL mini 5.1 Commissioning The rotary switch (5) is for switching the device on and off and to select the dose time of penetration. In “Off“ – position the device is switched off completely, no waste of battery power. Nevertheless the battery should be removed from the laser if it is not used for a longer period because there is the risk of the battery leaking and then the risk of oxidation of the contacts. This causes a defect of the device! Before and after each treatment the device should be disinfected, see Chapter 7! In “Standby“ position the laser is powered up and waits for selection of the necessary dose (time). After selection of the dose the laser cannot be started promptly, but only after a security delay of 2 sec. Now the laser can be started by pressing the button (3). This button must be hold down during the whole penetration time because of security. After releasing, the laser will stop suddenly.

 Place the laser perpendicular to the area to be irradiated (see heading "Possibilities for use of Compact-Laser"),



At the end of every therapy session the rotary switch must turned again into OFFposition. The integrated timer starts promptly after pressing the button, the control LED glows yellow and indicates that the output power has the correct value and that the battery is OK. The timer stops the laser automatically after the chosen time for therapy and the LED becomes dark. Shorter times of irradiation than the shortest selectable time of 15 seconds: Release the push-button early and the laser stops immediately. Longer times of irradiation than the longest selectable time of 60 seconds: at the end of the therapy time, release the laser button (3) and start the therapy by pressing it again – and the next dose of selected time will start.

6

Compact - Laser Series CL mini

Instructions for use

5.2 Laser-point and distance of irradiation

Direction of the Laser Beam

The point of the Silberbauer - CL-Laser is created in the shape of a small tube that follows the cone. The point is easily found through it – the point, where the laserradiation radiates on the skin. Normally, nearly inaccessible points, like behind the ear are easily radiated with no problems. At the point there is a short light conductor. This light conductor serves among other things as mechanical protection for the heart of your therapy equipment, the laser diode. The impact point or the areas of operation are specified by this laser point. With all models the light emerges, whereby the size of points can be changed according to requirements through the choice of the distance from the skin.

The irradiation distance can be selected at will! Therefore the laser is allowed to be set on the skin's surface. The skin can also be pressed in with smooth pressure by the laser-point, to reduce the distance between deeper-set areas needing to be irradiated (e.g. area of abdomen). Apart from this the laser-point is conductive and is connected with the socket at the rear end of the laser battery. The point-searcher PS3 can be connected to this socket with a connecting cable. Herewith the laser-point can be used at the same time as searching point-peak for acupuncture points.

7

Compact - Laser Series CL mini

Instructions for use

5.3 Irradiation Angle To obtain optimal success during treatment, the laser must be positioned perpendicular to the skin's surface.

Low reflection, Optimal penetration depth = optimal success

wide reflection, lower penetration depth = less success

5.4 Use of the accessories If necessary put the bent light conductor or the power reducing tip onto the point until a limit is reached (see drawing):

Direction of the Laser Beam

Direction of the Laser Beam

Power-reducing-tip

Light Conductor, bent

Direction to put on

8

Direction of the Laser Beam

Compact - Laser Series CL mini

Instructions for use

5.5 Location of Acupuncture points with the Compact – Laser mini: 5.5.1. Preparation of the assembly As well as the Silberbauer Compact - Laser mini (without power reducing tip!) a Silberbauer Point Detector PS3 and a connection cable is required. Put one plug of the connecting cable into the rear socket of the laser. The other cable plug is required to be inserted into the golden socket of the Silberbauer PS3 instead of the point-search-tip. The point finder Silberbauer Punktsucher PS 3 must now be handed over into the hand of the patient. The laser-tip can now serve now as a point finder.

5.5.2. Acupuncture point detection on the body The Silberbauer Point Detector PS 3 indicates the electrical conductivity of the skin both optically (with higher or lower frequency of the installed light-diode) and acoustically (with a varying tone pitch). The latter can be heard by the doctor while focussing his eyes on the acupuncture point. Hence the laser tip is positioned slightly diagonally above the acupuncture point, which should be localized on the skin’s surface. The area assumed to be an acupuncture point is sought out; then search the area, where you suppose the acupuncture point is, without lifting the tip from the skin. The pressure of the tip should be light and consistent while searching. Continue the search in the direction of a higher tone or a quicker signal. The tone pitch reaches its maximum light and maximum pitch or frequency at the centre of the acupuncture point. The push-button must be pressed on the laser above the acupuncture point thus beginning the irradiation. The time of therapy programmed in the Silberbauer CompactLaser mini is optimised for this kind of application required in every model.

9

Compact - Laser Series CL mini

Instructions for use

5.5.3. Detection of ear- and skull acupuncture points The acupuncture points at the cranial zone because of Yamamoto and at the ear are “silent“ -in contrast to acupuncture points for the rest of the body. This indicates that the electrical conductivity of the skin is very low there. However if a disturbance in the organism is projected to the reflexion zones, the electric conductivity of the skin changes at the relevant acupuncture points and zones. These points can be located like with the body’s acupuncture. Very high tones appear at points with strong disturbances which should be irradiated.

5.6 Irradiation period and Absorption Doses Suggested references: e.g.: Baxter: Therapeutic Lasers – Theory and Practice Füchtenbusch/Bringmann: Laser Therapy and Laser Acupuncture, Treatment tables Tunér/Hode: Laser Therapy – Clinical Practice and Scientific Background Tunér/Hode: The Laser Therapy Handbook

5.6.1

Formule

Energy = Laser power x irradiation period Irradiation dose = Energy /unit area 5.6.2

Measuring units

Energy: in Joules (J) = Watt-seconds (Ws) Power: in milli-watt (mW)

1 mW = 0,001 W

Time: in seconds (s) Unit area: in cm² Irradiation doses: in J / cm² 10

Compact - Laser Series CL mini

5.6.3

Instructions for use

Calculation of the correct dose

Recommended dose for different applications Geriatrics Pain therapy new scars

old scars

Gynecology, Surgery Dermatology Children, depending of age

Dose (J/cm2): u

0,5

1

2

3

Sports, Physiotherapy

4

5

6

8

Necessary irradiation period in seconds/cm² to get a certain dose (left row) for different laser models (upper line): CL mini 8 20 Dose in Joule / cm² Region for skin:

in case of pain:

0,1 0,2 0,3 0,5 0,8 1 1,5 2 3 4 5 6 7 8 9 10 12

12 25 42 62 100 125 188 250 375 500 625 750 875 1000 1125 1250 1500

5 10 15 25 40 50 75 100 150 200 250 300 350 400 450 500 600

30 3 7 10 17 27 33 50 67 100 133 167 200 233 267 300 333 400

This table shows how more power saves time! Example: The area to be irradiated is 50 x 10 mm large and should be irradiated with a 8 mW-laser with 1 Joule per cm². It is observed from the table that: 1 Joule /cm² = 125 seconds /cm² with the 8 mW-laser, For 50 x 10 mm = 5 cm² would it be 5 x 125 = 625 seconds for time for, that are more than 10 minutes!

11

Compact - Laser Series CL mini

Instructions for use

Or:

for treatment of areas with help of the card: Place the card close to the wound and check which circle has the same area like the wound (e.g. 4x1,8J). At this circle you find the number how often this dose has to be applied at once (e.g. 4x) and the dose setting of your laser (e.g. 1,8J). Set your laser to this dose setting. Place the laser tip close to the rim of the wound, press the start button and remain pressing until the laser switches off. Now release the button and press it again. Repeat this corresponding to the number.

Example for model CL mini 30 – 658:

In the literature there are values between 0,54 and 3 J/cm2 recommended. Preset duration time in Joule at Silberbauer CL mini models: model: CL mini 8 - 658 CL mini 20 - 658 CL mini 30 - 658

at 15 seconds:

at 1 minute:

0,12 J 0,3 J 0,45 J

0,5 J 1,2 J 1,8 J

12

Compact - Laser Series CL mini

Instructions for use

For comparison between different Silberbauer laser models:

For penetration of this small wound (1cm2) dose) you will need following times:

Model:

with 1 J/cm2 (usual

Seconds:

CL mini 8 - 658 CL mini 20 - 658 CL mini 30 - 658

125 50 33

5.7 Control of Use of Lasers The Silberbauer Compact - Laser mini has a laser output power:

mechanism for control of the

The yellow light emittimg diode (2) glows when the laser works with 90% of its rated power at least.

5.8 Charge of the NiMH- Battery See manual of the battery charger! Attention! Don’t try to charge normal one use batteries!

13

Compact - Laser Series CL mini

Instructions for use

6 Possible dysfunctions of the laser Attention must be paid to the existing danger involved in meddling with a damaged instrument and being exposed to dangerous laser-radiations! If the yellow lighting LED does not glow once the start-button is pressed, then please leave the button and observe whether  A few seconds have passed after the rotary switch was switched on? (It takes about 2 seconds till the laser can be switched on)  Could the battery be flat? It is enough to recharge the flat battery for a few minutes and irradiation can begin for a short time! If the laser does not work in spite of a correct battery or fully charged battery, please do not make any further attempts, but send or bring the laser together with the battery for monitoring purposes to our service! Do not under any circumstance turn or pull the mains adapter or the battery out of the laser while it is switched on! In case of the tiniest loss of contact – possible after a dropped battery or laser – the laser-diode could be badly damaged! Any changes in the device is NOT allowed! Fluid traces or small colorless or white crystals at the battery or at contacts indicate that a battery or a rechargeable battery has leaked and the contacts do not work. In this case, please send the device to the service for professional cleaning!

14

Compact - Laser Series CL mini

Instructions for use

7 Cleaning, disinfection and maintenance To avoid any danger of infection, the laser point must be disinfected before and after each treatment (and the power-reducing-tip and the bent light conductor). The laser is NOT water-tight and may NOT put into an immersin! So it must be cleaned carefully at first with a non-woven cloth moistened with tap water to remove all kinds of contamination. No liquid should be allowed to enter the openings. Then it can be wiped off carefully with a certified non-alcoholic surgical disinfection 1) (always observe its leaflet!). The laser point itself can also be cleaned and disinfected like above. The drill of the “power-reducing-tip“ can be cleaned with a toothpick and thereafter be cleaned and disinfected like above or it can be put into a disinfection bath (always observe the leaflet of the disinfection fluid!). For this, the power-reducing-tip must be pulled out of the laser always. The "bent light conductor" can be cleaned and disinfected like the laser top. The rear surface is well protected with a black hull made out of synthetic material. If this surface does get soiled the hull must be taken off. The lighting cable can then be proceeded to be cleaned and disinfected, see laser-point. Ensuing which the hull must remain attached to the lighting cable again, in such a way that the lighting cable just touches the front-surface of the laser point after the hull is pulled up, whereby the hull has to loom until the end of the cylindrical area of the laser point.

Light conductor, bent Direction of the Laser Beam Direction to put on

8 Waste management of laser and accessory For waste management please regard the valid legal regulations of each country/region! Disposal of the device: Not like household waste, but in the nearest receiving depot for disposal of electric devices! The batteries have to be brought to the next receiving depot for special waste disposal.

1

e.g. Mikrobac forte oder Microbac Tissues by BODE; the agent must be suitable for Plexiglas!

15

Compact - Laser Series CL mini

Instructions for use

9 Warranty According to the product liability law, general conditions apply to liability insurance (AHVB), supplementing general conditions for the liability insurance (EHVB) and the special conditions NR. 3401 valid in each case version. During the processing of our distributed devices the relevant legal safety regulations and editions in the valid in each case version are to be followed. We will provide free replacement of all parts which are defective because of material failure or mistake in production or we will repair them. Guarantee: All recently manufactured Silberbauer products: 3 years All used products: 1 year. Excluded from the warranty are batteries, accumulators and damage by effect of mechanical force eg dropping or by too high or too long working- or storage- temperature and damage by inappropriate handling. Also excluded from warranty are all damages at any device or accessory caused by leaked batteries. After demounting of the device by non-authorized ones there is no more warranty!

10 Laser inspection The CL-Laser mini must be inspected at regular intervals of 2 years.

10.1 Scope of inspection: 1. Examination of Output Power: Measuring Equipment required: Measuring device for the laser output with a large Si-photo-diode (at least 10 x 10 mm) is well suited for the measurement of every monitoring phase of the laser output and the wave-length of the CL mini Laser. Specification: Measuring accuracy:

+/- 5%

Measuring Process: The output power is measured when the laser is turned on and the sensor is hold perpendicular to the laser beam. Range of tolerance of the measured power: Nominal Power +/- 5% If the measured power is out of the mentioned range of tolerance, the laser must be calibrated or repaired. 2. Examination of controlling elements

16

Compact - Laser Series CL mini

Instructions for use

Due to danger of mechanical abrasion, the laser-button (3) must be checked and also the rotary switch (5). Scope of examination: a) Control of strokes of rotary switch: The switch must be turned to its 3 intended positions. The white point at the knob must corrspond to the labeling. b) Procedure for monitoring function of the rotary switch (5) and laser-button (3): Turn the rotary switch into its off position. Insert battery. Press the laser-button. No laser radiation has to emerge out of the instrument. Turn the rotary switch into its standby position. Press the laser-button. No laser radiation has to emerge out of the instrument. Turn the rotary switch into 15 s position. Press the laser-button. The instrument has to give laser-radiation for 15 s (control of time). Turn the standby-ready-switch into the position of 60 s. Press the laser-button. The instrument must radiate for 60 s (control of time).

3. Checking the readability of all labels All labels must be perfectly readible!

4. Checking of all accessories Inspection of all accessories by visual inspection for breaks or wear should be done. Also goggles for deep scratches which disturb the view.

10.2 Inspection Certificate To confirm the accurate functioning of the instrument the owner will receive an inspection certificate including its measured power. The results are given in the instruction book.

11 Laser dispatch The laser is delivered in its original packing, devoid of any defects by post as bulk goods. Pull the battery out of the laser during transport!

Attention! The Instruments Book is a Document! Please, send it together with all kinds of inspections or repair together with the device and accessories!

Storage temperature must not exceed 50 °C (122 °F) !

17

Compact - Laser Series CL mini

Instructions for use

12 Warning advices and Label Information : For the Laser there are used different warning labels depending of the model:

e.g. for the model CL mini 8 - 658:

All other models have the same warning labels with other values for power and wavelength.

Battery type and direction for insertion

Label outside of case:

Caution! Laser radiation!

Permissible temperature range

Application part type BF

Disposal of the device: Not like household waste, but in the nearest depot for disposal of electric devices! The batteries have to be brought to the nearest depot for special waste disposal.

Serial number

Year of manufacturing: coded at the end of the serial number: letter A for 2001, B for 2002, …… P for 2016, ….. etc.

Manufacturer

Consult Instructions for use!

The manufacturer is only considered responsible to bearing on security, reliability and capacity of the instrument, when A. changes or repairs are made by personnel authorized by him, B. the electrical installation of the room is according to the regulations of ÖVE-EN 7, C. the instrument is used in accordance with the directions of use. The instrument must not to be used with volatile gases or fumes during narcosis. This could cause sparks in the button or at the contacts. Apart from normal valid regulations the “Instructions to avoid explosive dangers in operational equipment“of BM for social administration Zl. V-88015-17 are to be considered in the advisory statement made by the medical experts from 03.02.1968 and ÖVE-EN 7 regarding the use of the instrument in an atmosphere enriched with oxygen.

18
