READ THIS FIRST TEST CHART 2000 XPERT 3DI: QUICK START GUIDE So you have opened the package, seen the thick manual and are thinking, “what have I let myself in for”? Don’t worry, within ten minutes you will be happily flicking between all your familiar test charts. Just follow the following steps. 1.

2.

Before installing the software, check that your computer screen is set to the correct resolution: a.

Right click on the desktop and select Properties. This will show the Display properties window.

b.

Select the Settings tab. Check that the Screen resolution slider is on the correct value for your monitor. Most 17’’-19’’ monitors have a resolution of 1280x1024. Larger monitors may support higher resolutions. Test Chart XPert 3Di requires a minimum resolution of 1280 x 1024. Click on Apply

While you are in Display settings, you can smooth the characters displayed on the screen by turning on anti-aliasing as follows: a.

Select the Appearance tab and click on Effects

b.

Select the Use the following method to smooth edges of screen fonts check box and select Clear Type from the pull down list. Click on OK then Apply. You are now ready to start installing the software.

3.

Insert the CD. After a few seconds the Install wizard will appear and guide you through the installation process. If nothing happens click on Start and select Run. Browse for the Setup program on the CD and then click on OK

4.

Test Chart XPert 3Di will now appear in your program list and on the desktop.

5.

The software was provided with a USB Dongle. This must be inserted at all times when using the software. You may install the software on multiple computers but it can only be run on computers that have a Dongle inserted. One Dongle is provided with each license purchased.

6.

NB: Look after the Dongle carefully. The full license fee will be charged for replacement Dongles that are lost or stolen.

2

T E S T

C H A R T

2 0 0 0

X P E R T

3 D I

7.

When you first run the program, the calibration screen will be displayed. If you are using a dual monitor system, drag this window onto the second monitor and ensure that it is properly positioned and sized to fill the window.

8.

Measure the size of the E and the blue box and enter the measurements into the corresponding boxes.

9.

Measure the chart viewing distance – patients’ eyes to the chart (to the mirror and back if a mirror is being used). Enter this distance in centimetres.

10. Click on OK to save this information. You are now ready to start testing! 11. Move the mouse cursor to the top of the screen to display the primary toolbar and to the bottom of the screen to show all the options for each test. Alternatively, press the function keys on the keyboard and the horizontal and vertical cursor control keys. Test Chart XPert 3Di is a very powerful system with an enormous array of tests and options. However, the user interface is very straightforward and most users say that they feel completely at home using it within a day or so. Unfortunately, you now need to read the manual!If you have any queries, don’t hesitate to ring the helpline 01707 263195

INSTALLING THE USB INFRA-RED RECEIVER The USB receiver has been designed to work with the IR handset for Test Chart XPert(NB: it is not suitable for use with the handset shipped with Test Chart 2000 Original). Before using the USB receiver it is necessary to install the appropriate drivers which are contained on the accompanying CD. 1.

Insert the CD (This will automatically run the Install wizard for Test Chart XPert 3Di . If Test Chart XPert 3Di is already installed on the computer, select Cancel)

2.

Connect the USB IR receiver to the USB port

3.

The computer should detect a new USB device and automatically run the wizard to find the appropriate drivers. It should find the drivers on the CD-ROM and eventually report that the new USB device has been successfully installed.

4.

Run Test Chart XPert 3Di and select Setup from the menu

3

T E S T

C H A R T

2 0 0 0

X P E R T

3 D I



Select the IR remote tab and select Enable IR remote control



Select the appropriate COM port. This will depend on the configuration of your computer. When in doubt, select each one in turn and press a button on the handset noting if the green “light” flashes on the screen. Alternatively, try clicking on Search to automatically identify the Com port.



Click on OK to save these settings



The handset should now allow you to control Test Chart XPert 3Di .

LINKING YOUR PC AND TABLETS/ PHONE Test Chart XPert 3Di introduces a two way link with a variety of tablets and smartphones including the iPad, iPhone and most Android devices. This link requires the PC and the tablet or phone to be on the same network. We recommend that the PC is connected to the wireless router/hub using a network cable (although it could be connected via WiFi). The tablet or phone needs to be connected via WiFi.

4

T E S T

C H A R T

2 0 0 0

X P E R T

3 D I

INSTALLING AIR DISPLAY Before using the tablet feature you must first install a program known as Air Display on BOTH the PC and your tablet or phone. The app for the iPad and iPhone is downloadable from the App store at a cost of around £7. The app for Android devices can be downloaded from the Android/ Google store. The PC program can be downloaded from http://avatron.com/apps/air-display.

When you have installed the software on the tablet, the Air Display icon will be displayed on the desktop as shown below.

5

T E S T

C H A R T

2 0 0 0

X P E R T

3 D I

Ensure that your tablet is connected via WiFi to the same network as the PC and then run Air Display on the tablet / phone. This will display the screen shown below.

Ensure that Air Display is running on your PC (this will normally run automatically when you start Windows). Depending on the version of Windows you are using, an icon will now appear in the Windows taskbar at the bottom of the screen as shown below.

6

T E S T

C H A R T

2 0 0 0

X P E R T

3 D I

Clicking on this icon will display the menu shown below.

The name of all devices running Air Display on the network should be displayed. Select the device that you wish to connect. The screen will then flicker slightly and the desktop should now appear on the tablet/ phone screen as shown below. The tablet / phone screen has now become part of your extended desktop and when you move the mouse cursor off the edge of your PC desktop (usually the left edge) it will now appear on your tablet/phone screen.

7

T E S T

C H A R T

2 0 0 0

X P E R T

3 D I

To configure Test Chart Xpert 3Di to work with your tablet / phone, select Setup from within the Test Chart program and then select the Windows Positioning tab as shown below.

The displays currently connected to your PC are represented by the blue rectangles at the top of this screen. In this case, there are two monitors connected (1 and 2) and an iPad Mini (3). If you have a single monitor attached to the PC, the tablet /phone will be labelled “2”. Details of how to configure the main Test Chart Window and Desktop window are given later on in 8

T E S T

C H A R T

2 0 0 0

X P E R T

3 D I

this manual. For now, you must simply ensure that the correct monitor is selected for the Tablet window – in this case “3”. The tablet can be used as an interactive remote control or for displaying a wide range of near vision tests.

9

T E S T

C H A R T

2 0 0 0

X P E R T

3 D I
